Every body likes pictures

[sting]

This defiantly aint water!
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[sting]

I stepped up my fuses tonight and the circuits held -- so it was a dumb arithmetic mistake after all

but now I am moving some of the dirtiest corn I ever fought - The lift auger in question here in now jamming at full feed and stalling the 1/2 hp used washing machine motor. I am sure full feed doesn't help

so I took the contraption apart again and made two improvements
1- I cut a gap into the Bugle for an adjustable sort of blast gate -vs the fixed reducer of the past. Now I have another method of mix variation

2 - I took a 3 inch PVC Y split it and inserted a piece of 1/4 inch hardware cloth - sort of skinny really mini Kan-Burn and hung this on the end of the fall out from the space shuttle and just above the 1/2 inch large junk cleaning screen. I should have taken pics as I cut and fitted but at the time I was possessed to see if I could even do it! its hooked to my salvaged industrial dryer - now my corn/pellet dust collection

this should condition 4 to 5 bushel a minute and Ill have to slow the auger to accommodate the new bottle neck and new slower delivery rate from the space shuttle out door storage.



My goal here is not to super clean the fuel -- just get the Loins share of the dirt removed before the seed is dried from storage to burnable moisture levels.

The first cleaner I made some seasons ago would almost polish each seed -- that was over the top and got parked very soon
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[Ahshucks]

You got a bigger belt wheel for that 1/2 HP motor?
_________________
Profit/Turnaround Expert: http://webpages.charter.net/rennhack1/index.html

[sting]

the driven pulley is a proprietary hub and pulley of the international pull type combine I salvaged this bin from. I suppose I could machine some modern pulley on to it but its so close to the floor that sizing up wouldn't get me far.

Note the pics I am already too close to the boiler room ceiling joist and I don't want to pound a hole in the floor for pulley clearance

yet

With the bin baffled I was getting about a bushel a minute - Non-Baffled Full feed may have been too much anyway. Funny how size can make some girls happy!
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[CanadaJoe]

whats wrong with a bushel a minute?
_________________
Burning pellets and loving it.

[sting]

_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[tallcorn]

[nogaspains]

ROTFLMAO


Nice going Sting, now I have to find me a new project for my corn this winter.
_________________
LDJ 165K BOILER / Harman PC45 / Kan_Burn Cleaner/Mover - the original

[sting]

[sting]

I need one more auger

I had a flighting but the tubing was shot - so I cut the edges down to fit it in 6 inch PVC - made some wooden shims/bearings for the ends and did a little better job of documentation.

This is the receiving end - note the wooden bearing





and this is the outlet with the motor brackets


I must be getting old - this took all darn afternoon and some of my evening!
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[sting]

Loaded 10 bags of pellets into the feed cart system tonight

pictures soon of that

but I needed to test it finally

it gave me over 10 bushel a minuet

I just got back from the hardware store with the biggest and smallest pulley that they had for both ends -- my calcs say they should reduce my delivery to closer to 4.5 and I can cut my corn side to 2 to keep my mix a bit rich on the pellet side till it gets colder.
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[sting]

Well that don't work The cracked corn get sucked tight in the 1/4 inc mesh and blocks the vacuum

So I turned it 90 degrees and it keeps a bit more of the dirt out of the dryer but then that was the goal

Any way -- the feed system mixes a perfect 2 to 1 batch into the appliance bin in 15 seconds

The boiler is hot tonight

I am taking the rest of it off so I can wear my kick me sign and pet the cat
_________________
When you turn your boiler on -- Does it return the favor?
I am sorry - My responses are limited - You must ask the right question!

[CanadaJoe]

Thats about how long it takes me to dump one bag in the boiler, after my son has hauled them next to the boiler for me to load. That is an impressive time.
_________________
Burning pellets and loving it.

[CanadaJoe]

Just read the other thread Sorry to hear a bout your wheaties and your kick me sign makes more sense now
_________________
Burning pellets and loving it.

[sting]

I bolted some plywood to a piece of scrap pipe today just to see show it would work out!




and I became inpatient to try my home made auger -- plus I wasn't going to hand carry any more bags -- I had loaded 10 into the pellet bin already -- so I rigged the new pellet pig trough in the window over the auger and fired the business up with the dust collection system running and the auger powered with a couple extension cords -- still needs a little tuning and some remote switching would be nice -- not yet ready for prime time but its entertaining when the girls are out shopping!




I started with the fall out hole here a bit reduced but everything went fine - that plastic 6 inch auger handles the pellets with ease and tenderness so ill open this up to a full 4 inches next time -- and if that works maybe Ill build a 6 inch pellet pig trough and try a full feed !! But then I can only swing the bags in so fast and not over exert so maybe a bit more paced speed due to equipment isn't a bad thing
